System board and components
Figure 388: Removing the M.2 SSD (B)
Ê Pull the M.2 SSD out of its slot.
Ê If no new M.2 SSD will be installed:
Ê Fasten the screw to the corresponding hexagon stand-off (see orange
circles in figure

16.5.2.3 Concluding steps

Ê If applicable, install the riser module 1, see section
on page 71.
"Reassembling" on page 63
Ê
"Connecting the power cord" on page 67
Ê
"Switching on the server" on page 70
Ê
16.5.3 Replacing the M.2 SSD
Upgrade and Repair Unit
(URU)
Tools: – Phillips PH1 / (+) No. 1 screw driver
16.5.3.1 Preliminary steps
"Shutting down the server" on page 55
Ê
"Disconnecting the power cord" on page 56
Ê
"Getting access to the component" on page 58
Ê
522
384 on page 518).
Upgrade and Maintenance Manual
"Handling riser modules"
Hardware: 5 minutes
RX2540 M4
