System board and components
LAN M
USB3.0 1/2
LAN 1/ M
LAN 1
Figure 403: Bolts for OCP modules
Ê Remove the four OCP bolts (see circles).
Figure 404: Removing the crossbar
Ê Remove the three screws of the crossbar (see circles).
Ê Remove the crossbar.
538
VROC
Slot 8 (CPU2)
Slot 7 (CPU2)
Slot OCP module
COM 1
Upgrade and Maintenance Manual
Micro
SD
iRMC
S5
SATA
0-3
SATA
4-7
PWR4
TPM
SATA
ODD
RX2540 M4
