9.8.2

Handling the rear air grids for the riser module 2

Upgrade and Repair Unit
(URU)
Tools: Phillips PH2 / (+) No. 2 screw driver / hexagon screw driver 5 mm
9.8.2.1

Installing the air grid extension to riser module 2

Figure 183: Example: Installing the air grid extension to riser module 2 - HL
RX2540 M4
Upgrade and Maintenance Manual
Expansion cards and backup units
Hardware: 5 minutes
275
