Hard disk drives (HDD) and solid state drives (SSD)
7.5.1.6

Connecting cables to the rear backplane

Ê Connect the corresponding cables to the backplane:
– The SAS cable, see figure
– The color-coded Oculink cables (for the PCIe SSD backplane type 1),
see figure 124 on page
Color
red
yellow
green
black
– The color-coded Oculink cables (for the PCIe SSD backplane type 2),
see figure 125 on page
Color
red
yellow
green
black
– The power cable, see figure 123-2, or figure 124-5, or figure 125-5.
– If applicable, the OOB cable, see figure 123-3, or figure 124-6, or
figure 125-6.
214
123 on page
210, 1-4:
Connector on PCIe SSD backplane
211, 1-4:
Connector on PCIe SSD backplane
Upgrade and Maintenance Manual
210, 1.
"P0_X1"
"P1_X2"
"P2_X3"
"P3_X4"
"P1_X1"
"P2_X2"
"P3_X3"
"P4_X4"
