2: C i/o
onTrol
Control I :P03.02
▲
01:2,3 wire Control
▼
02:DI1 Function
03: DI2 Function
3: e
nhanCemenTs
Enhanceme :P01.09
▲
01:S Curve Acc1
▼
02:S Curve Dec1
03:Jog Acc Time
DuRA
GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
pulse
Chapter 3: Keypad Operation and Quick-Start
Parameters in the Control I/O menu:
1 P302 2/3 Wire Operation Mode
2 P303 Multi-Function Input (DI1)
3 P304 Multi-Function Input (DI2)
4 P305 Multi-Function Input (DI3)
5 P306 Multi-Function Input (DI4)
6 P317 Multi-Function Output Terminal 1 (Relay 1)
7 P318 Multi-Function Output Terminal 2 (Relay 2)
8 P402 Analog Input 1 (AI1) Function
9 P403 Analog Input 2 (AI2) Function
10 P405 AI1 – I/V Selection
11 P406 AI2 – I/V Selection
12 P409 Analog Frequency Command for Reverse Run
13 P410 AI1 Input Bias (Offset)
14 P411 AI1 Input Bias (Offset) Polarity
15 P412 AI1 Input Gain
16 P413 AI1 Filter
17 P415 AI2 Input Bias (Offset)
18 P416 AI2 Input Bias (Offset) Polarity
19 P417 AI2 Input Gain
20 P418 AI2 Filter
21 P450 Analog Output 1 (AO1)
22 P451 AO1 Gain
23 P452 AO1 Negative Value Handle
24 P453 AO1 0~20mA/4~20mA Selection
25 P460 AO1 Output Constant Level
26 P501 Multi-Speed 1
27 P502 Multi-Speed 2
28 P503 Multi-Speed 3
29 P504 Multi-Speed 4
Parameters in the Enhancements menu:
1 P109 S-curve Accel Time 1
2 P110 S-curve Decel Time 1
3 P113 Jog Acceleration Time
4 P114 Jog Deceleration Time
5 P500 Jog Frequency
6 P119 Skip Frequency 1 Upper Limit
7 P120 Skip Frequency 1 Lower Limit
8 P125 DC Injection Current Level
9 P126 DC Injection Time During Start-up
10 P127 DC Injection Time During Stopping
11 P128 Start-Point for DC Injection During Stopping
12 P200 Volts/Hertz Settings
13 P201 Slip Compensation Gain
14 P225 Slip Compensation Filter
15 P202 Torque Compensation Gain
16 P203 Torque Compensation Filter
17 P210 PWM Carrier Frequency
18 P211 Control Mode
19 P218 Zero Speed Select
20 P625 Upper Limit of Output Frequency
21 P223 Automatic Energy-Saving Operation
22 P224 Power Saving Gain
23 P226 Slip Deviation Level
24 P227 Slip Deviation Detection time
25 P228 Slip Deviation Treatment
Page 3–7
