Automation Direct DURApulse GS4 User Manual page 312

Chapter 5: Serial Communications
s M
erial ODbUs
The DURA
pUlse
s a
TaTus ddresses
Description
Status
Monitor Error Codes
1
Page 5–6
s a
tatUs DDresses
GS4 AC drive has status memory addresses that are used to monitor the AC drive.
(r o )
ead nly
GS4 Status Addresses (Read Only)
Range
0: No Error
1: Overcurrent during Accel (ocA)
2: Overcurrent during Decel (ocd)
3: Overcurrent during normal speed
(ocn)
4: Ground Fault (GFF)
5: IGBT short circuit (occ)
6: Overcurrent during Stop (ocS)
7: Overvoltage during Accel (ovA)
8: Overvoltage during Decel (ovd)
9: Overvoltage during normal speed
(ovn)
10: Overvoltage during Stop (ovS)
11: Low voltage during Accel (LvA)
12: Low voltage during Decel (Lvd)
13: Low voltage during normal speed
(Lvn)
14: Low voltage during Stop (LvS)
15: Input phase loss (OrP)
16: IGBT Overheat 1 (oH1)
17: Cap Overheat 2 (oH2)
18: Thermister 1 open (tH1o)
19: Thermister 2 open (tH2o)
20: Power Reset Off (PWR)
21: Overload (oL) (150% 1Min,
Inverter)
22: Motor1 Thermal Overload (EoL1)
23: Motor2 Thermal Overload (EoL2)
24: Motor Overheat-PTC (oH3)
25: reserved
26: Over Torque 1 (ot1)
27: Over Torque 2 (ot2)
28: Under current (uc)
29: reserved
30: EEPROM write error (cF1)
31: EEPROM read error (cF2)
32: reserved
33: U phase current sensor detection
error (cd1)
34: V phase current sensor detection
error (cd2)
35: W phase current sensor detection
error (cd3)
36: CC Hardware Logic error 0 (Hd0)
37: OC Hardware Logic error 1 (Hd1)
38: OV Hardware Logic error 2 (Hd2)
39: OCC Hardware Logic error 3 (Hd3)
(table continued next page)
DuRA
pulse
40: Motor auto tune error (AuE)
41: PID Feedback loss (AFE)
42~47: reserved
48: Analog input signal loss (ACE)
49: External Fault (EF)
50: Emergency Stop (EF1)
51: Base Block (bb)
52: Password Error (Pcod)
53: Software Code lock (ccod)
54: PC Command error (CE1)
55: PC Address error (CE2)
56: PC Data error (CE3)
57: PC Slave error (CE4)
58: PC Communication Time Out
(CE10)
59: PC Keypad Time out (CP10)
60: Braking Transistor Fault (bf)
61: Y-Delta connection Error (ydc)
62: Decel Energy Backup Error (dEb)
63: Over Slip Error (oSL)
64: Electromagnet switch error (ryF)
65~71: reserved
72: STO Loss1 (STL1)
STO1~SCM1 internal hardware
detect error
73: ES1 Emergency Stop (S1)
74: In Fire Mode (Fire)
75: reserved
76: Safety Torque Off function active
(STO)
77: STO Loss2 (STL2)
STO2~SCM2 internal hardware
detect error
78: STO Loss3 (STL3) – STO1~SCM1
and STO2~SCM2 internal
hardware detect errors
79: U Phase Short (Uoc)
80: V Phase Short (Voc)
81: W Phase Short (Woc)
82: U Phase Loss (UPHL)
83: V Phase Loss (VPHL)
84: W Phase Loss (WPHL)
85~89: reserved
90: PLC Force Stop (FStp)
91~98: reserved
99: CPU Command error (TRAP)
100~110: reserved
111: InrCom Time Out (ictE)
GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
Modbus Address
Hex Dec Octal
2100 48449 20400
