P9.28 RS485 Direction Command
Range/Units (Format: 16-bit binary)
0: Forward
1: Reverse
This parameter sets the direction for the Run Command.
P9.29 RS485 External Fault
Range/Units (Format: 16-bit binary)
0: No Fault
1: External Fault
Use this parameter to initiate an external fault via RS-485.
P9.30 RS485 Fault Reset
Range/Units (Format: 16-bit binary)
0: No Action
1: Fault Reset
Use this parameter to reset a fault via RS-485.
P9.31 RS485 JOG Command
Range/Units (Format: 16-bit binary)
0: Stop
1: Jog
Use this parameter to issue a Jog Command via RS-485.
NOTE: Do not write both RUN (P9.27) and JOG (P9.31) Commands in the same write instruction. Use
separate write instructions from the master computer or PLC.
When controlling the drive via RS-485, do not send a Jog Command while the drive is
running. Also, do not send a Run Command while the drive is jogging. When the second
command is sent, the drive will respond with "Illegal Data Value."
P9.32 reserved
P9.33 GS4 Drive Rated Amps
Range/Units (Format: 16-bit unsigned)
0�00~655�34A
This parameter shows the rated currents of the GS4 AC Drives. The rated currents are listed
according to the ID codes shown in P9.42.
• By default, the current ratings shown are for light duty (variable torque)�
• To display normal duty (constant torque) current ratings, set P6�34 (Variable/Constant Torque Duty
Selection) to 1�
