1. REMOVE DIN CONNECTOR SCREW,
DIN CONNECTOR, GAKSET, AND
THUMB SCREW. SLIDE COIL AWAY
FROM VALVE.
AVS VALVE
1. REMOVE DIN CONNECTOR SCREW,
DIN CONNECTOR, GAKSET, AND
THUMB SCREW. SLIDE COIL AWAY
FROM VALVE.
AVS VALVE
Control Distribution Blocks
Setup Instructions
DIN CONNECTOR
SCREW
DIN CONNECTOR
DIN CONNECTOR TO
COIL GASKET
COIL
THUMB SCREW
Control Distribution Blocks
Setup Instructions
DIN CONNECTOR
SCREW
DIN CONNECTOR
DIN CONNECTOR TO
COIL GASKET
COIL
THUMB SCREW
2. ASSEMBLE VALVES ONTO MANIFOLD.
USE GASKETS, SCREWS, AND SPLIT
WASHERS SUPPLIED WITH MANIFOLD.
TORQUE RETAINING SCREWS 9-18 IN-LBS.
MANIFOLD
2. ASSEMBLE VALVES ONTO MANIFOLD.
USE GASKETS, SCREWS, AND SPLIT
WASHERS SUPPLIED WITH MANIFOLD.
TORQUE RETAINING SCREWS 9-18 IN-LBS.
MANIFOLD
RETAINING
SCREW
GASKET
RETAINING
SCREW
GASKET
