Chapter 7: GSoft2 – Getting Started
PA RAMETERS: Opens GSoft2 drive parameters table. The Parameters screen allows the user
to upload and download entire configurations to and from the drive. Individual
parameters can be changed "live" as well. There is also the ability to Open and Save files
on the PC's hard drive, and the ability to Compare parameter information to a drive's
default values. See the online help file for more information.
KE YPAD: Opens a graphical representation of the drive's keypad.
Several buttons will be grayed-out (ESC, MENU, and several
other keys are non-functional).
Operational Instructions:
To enable the Jog (F1), RUN, FWD/REV, and STOP/RESET
buttons and to allow changes to the drive's speed, please see
the GSoft2 online help file (must set P3.00/P3.01 and P4.00/
P4.01 for the drive to accept commands from RS485).
