Chapter 4: AC Drive Parameters
P8.15 reserved
P8.16 reserved
P8.17 reserved
P8.18 reserved
P8.19 reserved
P8.20 PLC Buffer 1
P8.21 PLC Buffer 2
P8.23 PLC Buffer 4
P8.24 PLC Buffer 5
P8.25 PLC Buffer 6
P8.26 PLC Buffer 7
P8.27 PLC Buffer 8
P8.28 PLC Buffer 9
P8.29 PLC Buffer 10
P8.30 PLC Buffer 11
P8.31 PLC Buffer 12
P8.32 PLC Buffer 13
P8.33 PLC Buffer 14
P8.34 PLC Buffer 15
P8.35 PLC Buffer 16
P8.36 PLC Buffer 17
P8.37 PLC Buffer 18
P8.38 PLC Buffer 19
P8.39 PLC Buffer 20
Range/Units (Format: 16-bit unsigned)
0~65535
Parameters P8.20~P8.29 can be used for conveniently transferring data to third party devices.
These buffers are used as a data memory storage location so that other devices can access
them from those parameter addresses. Users can change these parameter value by keypad or
communication. This data will be retained on a power cycle.
The internal GS4 PLC can read and write to these Parameters (as well as all GS4 Parameters) using
the RPR (Read Parameter) and WPR (Write Parameter) functions. So, these buffers can be used
to transfer information from the internal PLC to external devices without having to program the
external device to read data separately from the internal PLC and the Drive.
Page 4–180
DURA
GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
pulse
Type Hex Addr Dec Addr
~ 080F 42064
~ 0810 42065
~ 0811 42066
~ 0812 42067
~ 0813 42068
Type Hex Addr Dec Addr
R/W 0814 42069
R/W 0815 42070
R/W 0817 42072
R/W 0818 42073
R/W 0819 42074
R/W 081A 42075
R/W 081B 42076
R/W 081C 42077
R/W 081D 42078
R/W 081E 42079
R/W 081F 42080
R/W 0820 42081
R/W 0821 42082
R/W 0822 42083
R/W 0823 42084
R/W 0824 42085
R/W 0825 42086
R/W 0826 42087
R/W 0827 42088
Default
0
