Fan Removal (continued)
f C
rame
Applicable models:
GS4-4025, GS4-4030, GS4-2020, GS4-2025, GS4-2030
1 Use slotted screwdriver to remove cover.
Disconnect the fan power. Pull out the fan after loosening screws. The fan label should face
2
towards the inside of the drive. Screw torque 10 - 12 kg·cm (8.7 - 10.4 lb·in)
Remove poWeR fRom dRIve pRIoR to INstAllAtIoN ANd/oR RemovAl of AccessoRIes.
