Appendix A: Accessories
Fan Removal (continued)
f e
rame
Applicable models:
GS4-2060, GS4-2075, GS4-2100, GS4-4125, GS4-4150
Loosen screw 1-4 (as shown in the figure
1
below), and disconnect the fan power then
remove the fan.
Screw torque: 24 - 26 kg·cm (20.8 - 22.6 lb·in)
1
2
3 Loosen screw 1 and screw 2 (as shown in the figure below), and disconnect fan power before
removing the fan.
Screw torque: 24 - 26 kg·cm (20.8 - 22.6 lb·in)
Remove poWeR fRom dRIve pRIoR to INstAllAtIoN ANd/oR RemovAl of AccessoRIes.
Page A–52
3
4
DuRA
pulse
Loosen screw 1 - 4 (as shown in the figure below),
2
and disconnect the fan power then remove the
fan.
Screw torque: 24 - 26 kg·cm (20.8 - 22.6 lb·in)
1
2
3
4
1
2
