Chapter 5: Serial Communications
baC p
neT roToCol
Date: July 24, 2014
Vendor Name: AutomationDirect
Product Name: GS4
Product Model Number: GS4
Applications Software Version: Ver 01.04- 201406 Firmware Revision: Ver 01.04 BACnet
Protocol Revision: 7
Product Description:
ADC GS4 is a Variable Frequency AC motor Drive with BACnet embedded.
In GS4, the BACnet connection is by MS/TP, RS-485-based. GS4 provides a BACnet communication
function that permits it as a server and supports BIBBs defined by the BACnet B-ASC.
GS4 BACnet provides the capability to control and monitor the GS4 machine.
BACnet Standardized Device Profile (Annex L):
☐ BACnet Operator Workstation (B-OWS)
☐ BACnet Building Controller (B-BC)
☐ BACnet Advanced Application Controller (B-AAC)
☑ BACnet Application Specific Controller (B-ASC)
☐ BACnet Smart Sensor (B-SS)
☐ BACnet Smart Actuator (B-SA)
List all BACnet Interoperability Building Blocks Supported (Annex K):
Data Sharing BIBBs
Data Sharing-ReadProperty-B (DS-RP-B)
Data Sharing-WriteProperty-B (DS-WP-B)
Data Sharing-ReadPropertyMultiple-B (DS-RPM-B)
Device and Network Management BIBBs
Device Management-Dynamic Device Binding-B (DM-DDB-B)
Device Management-Dynamic Object Binding-B (DM-DOB-B)
Device Management-DeviceCommunicationControl-B (DM-DCC-B)
Segmentation Capability:
☐ Segmented requests supported
☐ Segmented responses supported
Standard Object Types Supported:
Analog Value
Binary Value
Device
Object instantiation is static. Refer to table at end of this document for object details.
Page 5–24
i C
mplemenTaTion onformanCe
Window Size
Window Size
DuRA
pulse
s
TaTemenT
