Fan Removal (continued)
f f
rame
Applicable models:
GS4-4175, GS4-4200
Loosen the screws, disconnect the fan power,
1
then remove the fan.
Screw torque: 24 - 26 kg·cm (20.8 - 22.6 Ib·in)
1
4
3
2
Loosen the screw and remove the cover.
3
Screw torque: 24 - 26 kg·cm (20.8 - 22.6 lb·in)
Loosen the screws and disconnect the fan power, then remove the fan.
4
Screw torque: 14 - 16 kg·cm (12.2 - 13.9 Ib·in)
11
10
9
Remove poWeR fRom dRIve pRIoR to INstAllAtIoN ANd/oR RemovAl of AccessoRIes.
DuRA
GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
pulse
Loosen the screw and remove the cover.
2
Screw torque: 14 - 16 kg·cm (12.2 - 13.9 Ib·in)
1
7
5
6
11
10
9
Appendix A: Accessories
4
3
2
8
Page A–53
