l r d
ine eaCTor imensions
See our website:
Mounting feet with multiple mounting slots allow replacement of most other reactors using
existing mounting holes. Use four bolts to mount the LR reactors.
LR-4200
6.76
[171.7]
9.00
[228.6]
9.00
[228.6]
5.75
[146.2]
1.76
[44.7]
3.52
[89.5]
5.64
[143.3]
4.20
[106.6]
MOUNTING
DuRA
GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
pulse
(Units = in [mm])
www.AutomationDirect.com
10.12
[257.1]
3.52
[89.5]
0.50
[12.7]
4.25
[108.0]
2.33
[59.2]
3.60
[91.4]
MOUNTING
4.75
[120.6]
for complete engineering drawings.
LR-4250, LR-4300
Appendix A: Accessories
Page A–19
