Chapter 1: Getting Started
3)
Frames D(0) through E:
Ensure that the angle between the
lifting eyes and the lifting device is
within the specification, as shown.
Frames F through G:
Ensure that the angle between
the lifting eyes and the lifting
device is within the specification,
as shown. Use a spreader bar to
avoid bending the lifting eyes.
DuRA
Page 1–18 GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
