  • Page 1 Terminator I/O MODBUS Base Controller User Manual Manual Number T1K–MODBUS–M...
  • Page 2 WARNING Thank you for purchasing automation equipment from Automationdirect.com. We want your new DirectLOGIC automation equipment to operate safely. Anyone who installs or uses this equipment should read this publication (and any other relevant publications) before installing or operating the equipment. To minimize the risk of potential safety problems, you should follow all applicable local and national codes that regulate the installation and operation of your equipment.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1: Introduction Manual Overview ..............1–2 The Purpose of this Manual .
  • Page 4 Table of Contents Chapter 4: Using the T1K–MODBUS Setup Tool Configuring the T1K–MODBUS Port ..........4–2 Installing the Setup Tool .
  • Page 5 Manual Revisions If you contact us in reference to this manual, be sure to include the revision number. Title: Terminator I/O MODBUS Base Controller User Manual Manual Number: T1K–MODBUS–M Edition Date Description of Changes 1st Edition 08/01 Original Issue...

  • Page 6: Chapter 1: Introduction

    Introduction In This Chapter..— Manual Overview — Introduction to MODBUS — Terminator I/O System — T1K–MODBUS Base Controller...

  • Page 7: The Purpose Of This Manual

    1–2 Introduction Manual Overview The Purpose of This manual describes the installation and this Manual operation of the Terminator I/O MODBUS Base Controller (T1K–MODBUS). Supplemental The following manuals are essential to the proper use of your Terminator I/O Manuals MODBUS Base Controller. •...

  • Page 8: Manual Layout

    1–3 Introduction Manual Layout The contents of this user manual are as follows: Chapter Title What’s covered introduces MODBUS and describes both the Terminator Introduction I/O System and the T1K–MODBUS Base Controller provides module specifications, dip switch settings, port T1K–MODBUS pin–outs and wiring information.

  • Page 9: Introduction To Modbus

    1–4 Introduction Introduction to MODBUS MODBUS RTU (Remote Terminal Unit) Protocol is a messaging structure used to establish master–slave communications between intelligent devices. When a MODBUS master sends a message to a MODBUS slave, the message contains the address of the slave, the function, the data and a check sum. The slave’s response message contains fields confirming the master’s request, any data requested and an error–checking field.

  • Page 10: Terminator I/O System

    1–5 Introduction Terminator I/O System Terminator I/O is a modular system which combines the functions of terminal blocks and I/O modules for distributed I/O. Each Terminator I/O system has the following components: a Power Supply, a Base Controller, and one or more I/O Modules and I/O bases.

  • Page 11: T1K-Modbus Base Controller

    1–6 Introduction T1K–MODBUS Base Controller The T1K–MODBUS Base Controller is a slave module that functions as a controller for Terminator I/O on a MODBUS network. Note: It is recommended to use the T1K–MODBUS Base Controller in a “scan based” (polled) control system rather than in an “event–driven” control system. As a slave, the Base Controller does not have the ability to report an error condition to the MODBUS network master.

  • Page 12: T1K-Modbus Base Controller Specifications

    T1K–MODBUS Base Controller Specifications In This Chapter..— T1K–MODBUS Base Controller Specifications — Setting the DIP Switches — Setting the Rotary Address Switches — MODBUS Port Pin–out and Wiring — RJ12 Serial Port Pin–out and Wiring...
  • Page 13 2–2 T1K–MODBUS Specifications T1K–MODBUS Base Controller Specifications General Operating Temperature 32° F to 131° F (0° C to 55° C) Storage Temperature –4° F to 158° F (–20° C to 70° C) Ambient Humidity 30% – 95% relative humidity (non–condensing) Voltage Withstand 1500VAC, 1 minute (15–pin connector internal) Insulation Resistance...
  • Page 14 2–3 T1K–MODBUS Specifications RJ12 Serial Port Specifications Connector 6–pin female modular (RJ12 phone jack) Connection Port Type RS232C Protocol MODBUS RTU; Use to configure the MODBUS port using the T1K–MODBUS Setup Tool. Also use for firmware upgrades. Station Number 1 (Fixed) Baud Rate 9600bps, 19200bps (Dip Switch 6 selectable) Communication Data...

  • Page 15: Dip Switch Settings

    2–4 T1K–MODBUS Specifications Setting the DIP Switches DIP Switch The T1K–MODBUS controller has an eight position DIP Switch which controls baud Settings rates, addressing modes, the state of the outputs in an error condition, etc. The DIP Switch is located on the side of the unit, opposite the power supply. Note: Be sure to look closely at the DIP Switch default settings below.
  • Page 16 2–5 T1K–MODBUS Specifications The Communications Setting mode, DIP Switch 4, enables some of the MODBUS port communication parameters to be user set using the T1K–MODBUS Set Up Tool. The following tables describe the default and option modes. SW 4 Communication Setting Mode Default Mode Option Mode Default Mode:...
  • Page 17 2–6 T1K–MODBUS Specifications The Hold Outputs DIP Switch 5 determines the slave outputs’ response to a communications failure. If DIP switch 5 is in the ON position, the outputs in that slave unit will hold their last state when a communication error occurs. If OFF, the outputs in that slave unit will turn off in response to a communications error.

  • Page 18: Setting The Rotary Address Switches

    2–7 T1K–MODBUS Specifications Setting the Rotary Address Switches The T1K–MODBUS unit address is set by the two rotary switches on the front of the unit. Addresses are in hexadecimal format with valid address from 00 to F7, which is equivalent to 0 to 247 decimal. The addresses do not have to be sequential, but each station address must be unique.

  • Page 19: Modbus Port Pin-Out And Wiring

    2–8 T1K–MODBUS Specifications MODBUS Port Pin–out and Wiring MODBUS Port Pin Descriptions 5 VDC TXD2 Transmit Data (RS232C) RXD2 Receive Data (RS232C) RTS2 Ready to Send (RS–232C) CTS2 Clear to Send (RS–232C) 6 RXD2– Receive Data – (RS–422) Logic Ground Logic Ground TXD2+ Transmit Data + (RS–422) 10 TXD2 –...

  • Page 20: Rj12 Serial Port Pin-Out And Wiring

    2–9 T1K–MODBUS Specifications RJ12 Serial Port Pin–out and Wiring The Base Controller’s MODBUS port can be configured using the T1K–MODBUS Setup Tool via the RJ12 serial port. The “Using the T1K–MODBUS Setup Tool” chapter later in this manual discusses using the Setup Tool. The RJ12 port is also used to upgrade the firmware in the base controller.
  • Page 21 MODBUS RTU Functions and Addressing Modes In This Chapter..— T1K–MODBUS RTU Function Codes — Using T1K–MODBUS with DirectLogic PLC — Using T1K–MODBUS with MODBUS 584/984...

  • Page 22: Chapter 3: Modbus Rtu Functions And Addressing Modes

    3–2 MODBUS RTU Functions and Addressing Modes MODBUS RTU Function Codes MODBUS Function The following MODBUS RTU functions are supported by the T1K–MODBUS base Codes Supported controller. MODBUS RTU Function Function Code Read Output Table Read Input Table Read Holding Registers (when addressing mode is 584/984, this function is used to ac- cess analog output registers) Read Input Registers (when addressing mode...

  • Page 23: Directlogic Addressing Mode

    3–3 MODBUS RTU Functions and Addressing Modes DirectLogic Addressing Mode Using the The DirectLogic Addressing mode is set by placing Dip Switch 7 in the ON position. The following memory locations are supported by the T1K–MODBUS base controller in the T1K–MODBUS with DirectLogic Addressing Mode.

  • Page 24: 584/984 Addressing Mode

    3–4 MODBUS RTU Functions and Addressing Modes 584/984 Addressing Mode Note: ModScan32 is a Windows based application program that can be used as a MODBUS master to access and change data points in a connected slave device (T1K–MODBUS). The utility is ideally suited for quick and easy testing of MODBUS network slave devices.

  • Page 25: Chapter 4: Using The T1K-Modbus Setup Tool

    Using the T1K–MODBUS Setup Tool In This Chapter..— Configuring the T1K–MODBUS Port...

  • Page 26: Installing The Setup Tool

    4–2 Using the T1K–MODBUS Set Up Tool Configuring the T1K–MODBUS Port T1K–MODBUS Setup Tool (included with this manual) can be used to configure some of the MODBUS port communication parameters via the RJ12 serial port. The T1K–MODBUS DIP switch 4 must be in the ON position in order to use the Setup Tool to configure the MODBUS port parameters.
  • Page 27 4–3 Using the T1K–MODBUS Set Up Tool Selecting the PC Select the PC port that will be used to connect to the T1K–MODBUS base controller’s RJ12 serial port. Comm Port Configuring the The following window will be displayed when the Tool is communicating with the base controller’s RJ12 serial port.

  • Page 28: Appendix A I/O Module Hot Swap

    Appendix A I/O Module Hot Swap In This Appendix..— T1K–MODBUS I/O Module Hot Swap Feature...

  • Page 29: Check External 24Vdc Wiring Before Hot Swapping

    A–2 I/O Module Hot Swap T1K–MODBUS I/O Module Hot Swap Feature The “Hot Swap” feature allows Terminator I/O modules to be replaced with Terminator I/O system power ON. Be careful not to touch the terminals with your hands or any conductive material to avoid the risk of personal injury or equipment damaged.

  • Page 30: Hot Swap: I/O Module Replacement

    A–3 I/O Module Hot Swap Hot Swap: The following steps explain how to “Hot Swap” an I/O module. I/O Module 1. Remove I/O module from base. (If necessary, refer to the Terminator I/O Replacement Installation & I/O Manual for steps on removing an I/O module). 2.

  • Page 31: Appendix B: Analog Output Module Configuration

    Appendix B: Analog Output Module Configuration In This Appendix..— Analog Output Module Control Byte...
  • Page 32 B–2 Analog Output Module Configuration Analog Output Module Control Byte The Terminator I/O analog output modules are configured using the Module Control Byte located in the most significant byte of the most significant word of channel 1 of the module. The “I/O Memory Map and Analog Module Resolution” chapter in the Terminator Installation and I/O Manual (T1K–INST–M) covers memory mapping for the Terminator I/O modules.
