Ethernet communication cards must have their own unique IP address. While the card addresses
can be set for DHCP (IP address is set and can be changed by the network), we recommend using
static IP addresses. That way, the IP address of the drive will stay fixed. Either method requires
the IP addresses (and subnet masks) of the communication cards to be compatible with any other
devices that want to connect to the drive. For an easy subnet mask calculator, please visit
www.subnet-calculator.com.
NOTE: If at any point the communication card configuration becomes problematic, the
communication card can always be reset to factory defaults by entering a "1" into P9.63 Com
Card Factory Reset.
The following example will set the IP addresses of the PC and drive. Your actual addresses may
need to be different, depending on your local network.
s iP
et the aDDress Of the
Now the IP address of the drive must be set. This can be done in GSoft2 or by the drive's keypad.
NOTE: Changing an Ethernet communication parameter in the drive does not immediately affect
the communication card; there is a second set of registers in the comm card. Entering a value
of 2 in parameter P9.64 causes the drive to push the P9 communication parameters to the card.
Bits in P9.64 reset themselves automatically.
GSoft2 method
Connect to the drive thru the RS485 port. Once connected, the "IP Config button" will
become active. Click on it. The Overview tab that pops up shows the current drive
configuration. Click on the Basic tab to edit the IP address. Enter the following:
IP Configuration = Static
IP Address =
Subnet Mask = 255.255.255.0
Gateway =
Press Apply for the changes to take effect. (This effectively sets bit 1 in P9.64)
Keypad method
Enter the following parameter data in the drive keypad:
Enter a "2" into P9.64 (sets bit 1 = 1) and press "Enter" to transfer the network parameters to the
comm card. P9.64 will save the parameters to the card and will then reset P9.64 to zero.
DuRA
GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
pulse
Appendix B: Optional I/O and Communication Cards
gs4-Cm-eneTip ip a
gs4 D
rive
192.168.1.10
0.0.0.0 (or same as IP address 1st three octets; ex: 192.168.1.1)
GS4 IP Configuration
Parameter Set Value
P9.48
0
P9.49
192
P9.50
168
P9.51
1
P9.52
10
P9.53
255
P9.54
255
P9.55
255
P9.56
0
P9.57
192
P9.58
168
P9.59
1
P9.60
1
n
ddress and eTWork
Explanation
Set the IP to "Static"
IP address 1
IP address 2
IP address 3
IP address 4
Subnet Mask 1
Subnet Mask 2
Subnet Mask 3
Subnet Mask 4
Gateway Address 1
Gateway Address 2
Gateway Address 3
Gateway Address 4
C
onfiguraTion
Page B–9
