Appendix F: PID Control
P8.02 User Defined Format
Range/Units (Format: 16-bit binary)
Bi ts 0~3:
U ser defined decimal place
0000b: no decimal place
0001b: one decimal place
0010b: two decimal place
0011b: three decimal place
Bi ts 4~9: User defined unit
000xh: Hz
001xh: rpm
002xh: %
003xh: kg
004xh: m/s
005xh: kW
006xh: hp
007xh: ppm
008xh: 1/m
009xh: kg/s
00Axh: kg/m
00Bxh: kg/h
00Cxh: lb/s
00Dxh: lb/m
00Exh: lb/h
The user defined format sets the attributes (or units) that are enabled when P8.03 > 0. These
settings allow the user to define a display field according to specific system processes. The
frequency command signal will be scaled according to P0.04 (Max Output Freq) and P8.03 (User
Coefficient Max)
Example:
• P004 Max Output Freq = 60 Hz
• P800 User Display = 30 (User Defined)
• P802 User Defined Format = 0072h (unit = ppm, two decimal places)
• P803 User Defined Max = 11500
An analog frequency setting of 50% will result a 30Hz setting, but the keypad will display the
user format 57.50ppm (50% x 115.00ppm). Likewise a commanded frequency input value of
100.00ppm will result in an output frequency of 52.17Hz = (100ppm/115ppm) x 60Hz.
Note: Running in forward or reverse will display a positive value.
P8.03 User Defined Max
Range/Units (Format: 16-bit unsigned)
0: Disable
0~65535 (when P802 set to no decimal place)
00~65535 (when P802 set to 1 decimal place)
000~65535 (when P802 set to 2 decimal place)
0000~65535 (when P802 set to 3 decimal place)
User defined is enabled when P8.03 is not 0. The setting of P8.03 is linearly scaled to P0.04 (Max
Output Frequency).
See example in P8.02 for further information.
Page F–22
00Fxh: ft/s
010xh: ft/m
011xh: m
012xh: ft
013xh: °C
014xh: °F
015xh: mbar
016xh: bar
017xh: Pa
018xh: kPa
019xh: mWG
01Axh: inWG
01Bxh: ftWG
01Cxh: psi
01Dxh: atm
01Exh: L/s
01Fxh: L/m
020xh: L/h
3
021xh: m /s
3
022xh: m /h
023xh: gpm
024xh: cfm
