P7.06 PID Multi-Setpoint 1
P7.07 PID Multi-Setpoint 2
P7.08 PID Multi-Setpoint 3
P7.09 PID Multi-Setpoint 4
P7.10 PID Multi-Setpoint 5
P7.11 PID Multi-Setpoint 6
P7.12 PID Multi-Setpoint 7
Range/Units
000~10000%
Parameters P7.06~P7.12 are used to provide seven different PID Setpoints. Multi-Function
Input Terminals DI1~DI15 are assigned in parameters P3.03~P3.16 to select which one of the PID
Multi-Setpoints is to be used.
Multi-Function Input Terminal Function Settings (P3.03~P3.16) for Input Terminals DI1~DI16
(a
bbreviated listiNg
Setting: Function
0: No function
1: Multi-Speed/PID Multi-Setpoint
bit 1
2: Multi-Speed/PID Multi-Setpoint
bit 2
3: Multi-Speed/PID Multi-Setpoint
bit 3
DuRA
GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
pulse
;
iNcludes oNly settiNgs applicable to
Function Description
Setting a Multi-Function Input to 0 will disable that input The purpose of this
function is to provide isolation for unused Multi-Function Input Terminals
Any unused terminals should be programmed to 0 to make sure they have
no effect on drive operation.
When settings 1, 2, & 3 are selected and registers P706~P712 are populated,
the Multi-Function Inputs refer to PID Multi-Setpoints The SPs are determined
by P706~P712
1) In order to use the Multi-PID SPs, P7.06~P7.12 must be set, and P7.00≠0.
2) When all PID Multi-Setpoint inputs are off, the GS4 drive reverts to the PID
Setpoint Source (P702)
PID Setpoint
Bit 3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
pid)
Selection
Bit 2 Bit 1 PID Setpoint
OFF OFF P702: SP Source
OFF ON P706: Setpoint 1
ON OFF P707: Setpoint 2
ON ON P708: Setpoint 3
OFF OFF P709: Setpoint 4
OFF ON P710: Setpoint 5
ON OFF P711: Setpoint 6
ON ON P712: Setpoint 7
Appendix F: PID Control
Type Hex Addr Dec Addr
♦R/W 0706 41799
♦R/W 0707 41800
♦R/W 0708 41801
♦R/W 0709 41802
♦R/W 070A 41803
♦R/W 070B 41804
♦R/W 070C 41805
Default
000
