Automation Direct DURApulse GS4 User Manual page 305

P11.27 Digital Output Status at Fault
Range/Units (Format: 16-bit binary)
0~65535
P11.27 captures the value of P3.46 Digital Output Status at the instant of last drive fault. If another
fault occurs, the previous record will be overwritten.
Representation of bits:
• Bit1~Bit0: 00: RUN LED light off; STOP LED light on (Drive Stop)
01: RUN LED blink; STOP LED light on (Drive Decelerating during stopping)
10: RUN LED light on; STOP LED blink (Drive Standby)
11: RUN LED light on; STOP LED light off (Drive Run)
• Bit2: 1: JOG active
• Bit4~Bit3: 00: REV LED light off; FWD LED light on (Forward)
01: REV LED blink; FWD LED light on (Reverse to Forward)
10: REV LED light on; FWD LED blink (Forward to Reverse)
11: REV LED light on; FWD LED light off (Reverse)
• Bit5: 1: Factory parameters group opened state
• Bit6: 1: Advance parameter group opened state
• Bit7: 1: Operation command controlled by external terminal
• Bit8: 1: Main frequency controlled by communication
• Bit9: 1: Main frequency controlled by external terminal (AI)
• Bit10: 1: Operation command controlled by communication (PU)
• Bit11: 1: Parameters have been locked
• Bit12: 1: Copy command enable
• Bit15~Bit13:
P11.28 Drive Status at Fault
Range/Units (Format: 16-bit unsigned)
0~65535
P11.28 shows the Drive Status at the time of last drive fault. If another fault occurs, the previous
record will be overwritten.
DURA
GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
pulse
0: HOA mode OFF
1: HOA mode HAND-ON
2: HOA mode AUTO-ON
3: LOC/REM mode LOC-ON
4: LOC/REM mode REM-ON
Chapter 4: AC Drive Parameters
Type Hex Addr
Read 0B1B
Default
0
Type Hex Addr
Read 0B1C
Default
0
Dec Addr
42844
Dec Addr
42845
Page 4–211
