Chapter 1: Getting Started
M n
ODel UMber
GS4- 4 7P5
n i
aMePlate nfOrMatiOn
MODEL : GS4-21P0
INPUT : (Variable Torque / Constant Torque)
VT : 3PH 200-240V 50/60Hz 6.4A
CT : 3PH 200-240V 50/60Hz 6.1A
CT : 1PH 200-240V 50/60Hz 6.4A
OUTPUT : (Variable Torque / Constant Torque)
VT : 3PH 0-240V 5A 2.0KVA 0.75KW/1HP
CT : 3PH 0-240V 4.8A 1.9KVA 0.75KW/1HP
CT : 3PH 0-240V 2.4A 1.0KVA 0.37KW/0.5HP
FREQUENCY RANGE : 0-600Hz
SHORT CIRCUIT CURRENT : 100KA
IP20 / UL Open-Type with top cover removed
(rated -10°C to 50°C Ambient).
IP20 / NEMA 1 / UL Type 1 with top cover
Installed (rated -10°C to 40°C Ambient).
Refer to user manual.
GS4-21P0+W15170017
Ver : 01.00
Page 1–16
e
xPlanatiOn
Applicable Motor Capacity*
1P0: 1.0hp
7P5: 7.5hp
025: 25hp
060: 60hp
150: 150hp
300: 300hp
*Not all capacities are available in each voltage.
Input Voltage
2: 230VAC
4: 460VAC
Series Name
Automationdirect.com
MADE IN CHINA
DuRA
pulse
2P0: 2.0hp 3P0: 3.0hp
010: 10hp 015: 15hp
030: 30hp 040: 40hp
075: 75hp 100: 100hp
175: 175hp 200: 200hp
MODEL : GS4-41P0
INPUT : (Variable Torque / Constant Torque)
VT : 3PH 380-480V 50/60Hz 4.3A
CT : 3PH 380-480V 50/60Hz 4.1A
OUTPUT : (Variable Torque / Constant Torque)
VT : 3PH 0-480V 3.0A 2.4KVA 0.75KW/1HP
CT : 3PH 0-480V 2.9A 2.3KVA 0.75KW/1HP
FREQUENCY RANGE : 0-600Hz
SHORT CIRCUIT CURRENT : 100KA
IP20 / UL Open-Type with top cover removed
(rated -10°C to 50°C Ambient).
IP20 / NEMA 1 / UL Type 1 with top cover
Installed (rated -10°C to 40°C Ambient).
Refer to user manual.
GS4-41P0+W15150001
Automationdirect.com
Ver : 01.00
GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
5P0: 5.0hp
020: 20hp
050: 50hp
125: 125hp
250: 250hp
MADE IN CHINA
