nPaCking OUr
CAUTION: The larger GS4 DURA
permanently damaged during unpacking, unless the following instructions are followed carefully.
l e l
ifTing ye oCaTions and
1)
GS4 DURA
pUlse
D(0) through G have lifting eyes built in
to the four corners of the backplane, as
shown in this typical drawing.
2)
Frames D through E:
Ensure that the lifting hook properly
goes through the lifting eyes, as shown.
Frames F through G:
Ensure that the lifting hook properly
goes through the lifting eyes, as shown.
DuRA
GS4 AC Drive User Manual – 1st Ed, Rev A - 10/20/2017
pulse
aC D
pulse
AC drives, frame sizes D through G, can easily be
pUlse
i
nsTruCTions
AC drives frame sizes
Chapter 1: Getting Started
rive
Page 1–17
