Install the NVMe Cables

6. Disconnect the cables from the motherboard (2).
Carefully pull the NVMe card cables from the side of the chassis and remove
7.
them from the server.
Related Information
"Install the NVMe Cables" on page 124
■

Install the NVMe Cables

This is a cold-service procedure that must be performed by qualified service personnel. The
server must be completely powered down before performing this procedure.
Guide the NVMe card cables along the side of the chassis.
1.
124 SPARC S7-2 Server Service Manual • March 2017
