Remove A Pcie Card Carrier - Oracle SPARC T8-4 Service Manual

4. Remove the faulty PCIe card.
See "Remove a PCIe Card Carrier" on page
Related Information
"Understanding PCIe Root Complex Connections" on page 155
■
"PCIe Card Configuration" on page 158
■
"PCIe Carrier Handle and LEDs" on page 159
■
"Remove a PCIe Card Carrier" on page 161
■
"Remove a PCIe Card" on page 164
■
"Install a PCIe Card" on page 167
■
"Install a PCIe Card Carrier" on page 170
■
"Verify a PCIe Card" on page 171
■

Remove a PCIe Card Carrier

The SPARC T8-4 server supports single-wide and double-wide card carriers. The removal steps
are the same for both carrier types. This topic includes illustrations only for the single-wide
carrier.
If you are installing a PCIe card that requires a double-wide carrier, you must remove
Note -
two adjacent PCIe card carriers.
This procedure requires that you handle components that are sensitive to electrostatic
Caution -
discharge. This discharge can cause failure of server components.
Removing PCIe card carriers while the server is at the OpenBoot prompt is not
Note -
supported. The server must be either powered off, or booted into the Oracle Solaris OS.
Take the necessary ESD precautions.
1.
See "Prevent ESD Damage" on page
2. Locate the PCIe card carrier at the rear of the server.
See "Determine Which PCIe Card Is Faulty" on page 160
3. Determine if you are removing a PCIe card carrier from a running server.
If you are removing a PCIe card carrier from a server that is running (that is, if you are hot-
■
plugging the PCIe card), go to
161.
49.
to locate a faulty PCIe card.
Step 4.
Remove a PCIe Card Carrier
Servicing PCIe Cards 161
