2.5.4 Clearing Memory
All stored test conditions in instrument memory (100 setups) may be cleared.
all preset and option parameters are cleared as well as all memory locations. All
parameters will be reset to default values.
To clear setup memory:
With the instrument in MAIN MENU,
Press the numerical key [4] that corresponds to CALIBRATION. Instrument displays
message: "Enter Calibration Password".
Press [8][5][2][4][6] [ENTER] Instrument displays message: "Clear Memory?"
Press function key [YES] to clear all memory.
Press function key [NO] to abort the clear all memory function.
Press [EXIT] to return to MAIN MENU
2.6
To access PRESET SETUP, press the [MENU] function key at the top left hand corner of
the keypad and press the function key [PRESET]. Within PRESET SETUP there are 12
parameters: Pass Hold, Step Hold, AC Frequency, GB Frequency, IEC-601, GB Voltage,
Auto Range, Software AGC, Part No., Lot No., Serial No. and Start Wait. Refer to
Figure 2-18.
To access any of these 12 parameters, press the [↑] or [↓] arrow on the keypad to move
the backlit box to the desired parameter. The status window in the bottom left-hand
corner of the display shows the range for the selected parameter. Use the function keys
or the numerical keys and [ENTER] to set a PRESET parameter.
Operation
www.valuetronics.com
PRESET
PRESET SETUP
01. Pass Hold :
02. Step Hold :
03. AC Freq. :
04. GB Freq. :
05. IEC - 601 :
06. GB Voltage :
07. Auto Range :
08. Soft AGC :
09. Part No. :
10. Lot No. :
11. Serial No. :
12. Start W ait :
0.2 - 99.9s
Figure 2-18: PRESET SETUP
0.5 sec
0.3 sec
64 Hz
60 Hz
OFF
15.0 V
OFF
ON
OFF
Remote Lock Offset
