QuadTech Guardian 6100 Plus Instruction Manual page 125

3.2.2 RS232 Specifications
Data bits:
Stop bits:
Start dits:
Parity:
Baud Rate:
Flow Control:
EOS:
Selecting Baud Rate
Setting the baud rate is done in the [OPTION] submenu, ¶ 2.3.2.1.
Use RS-232 to set the baud rate, parity and flow control for the RS-232 interface. To
access RS-232 Setup, press [MENU], [2] and the function key [RS-232].
box is next to 'Select baud rate'. Use the [UP] or [DOWN] function key to select the
baud rate = 300, 600, 1200, 2400, 4800, 9600 or 19200. The default value is 9600 bps.
Use the [↓] arrow on the keypad so the backlit box is to the right of 'Select parity'. Use
the [UP] or [DOWN] function key to select the parity = ODD, EVEN or NONE. The
default value is NONE.
Use the [↓] arrow on the keypad so the backlit box is to the right of 'Flow control'. Use
the [UP] or [DOWN] function key to select the parity = NONE or SOFTWARE. The
default value is NONE.
Use the [EXIT] key to exit RS232 Setup and return to Option Menu.
3.2.3 RS232 Commands
The command set for the RS232 interface is the same as the IEEE-488 interface command
set listed in paragraphs 3.3.2 through 3.3.4 of this Instruction Manual.
Interface
www.valuetronics.com
8 (or 7 data bits and 1 parity bit)
1
1
None/Odd/Even
300/600/1200/2400/4800/9600/19200 bps
None/Software
CR + LF
RS232 SETUP
