Change the setting on the Valhalla to the 200V range.
Press [UP] to go to CAL step 5. (IRV 1kV Offset
Press [STOP]
Press [START]
Using keypad enter the reading from the voltmeter followed by the [ENTER].
Press [STOP] to accept reading.
Press [UP] to go to CAL step 6. (IRV 1kV Full
Change the range on the voltmeter to 2kV.
Press [STOP]
Press [START]
Using keypad enter the reading from the voltmeter followed by the [ENTER].
Press [STOP] to accept reading.
4.3.1.4
Connect the OUTPUT terminal of the Guardian 6100 Plus to a resistance box or
resistance standard. Connect an AC/DC current meter in series between the resistance
(box) and RTN/LOW terminal. Set the meter to AC current. Table 4-3 lists the loads for
the current calibration steps.
Mode
ACA
ACA
ACA
ACA
DC
DC
DC
DC
Page 168 of 177
www.valuetronics.com
AC Current Calibration
Table 4-3: Resistance Loads
Step # Voltage
CAL 7 1200 V
CAL 8 1200 V
CAL 9 1200 V
CAL 10 1200 V
CAL 11 1200 V
CAL 12 1200 V
CAL 13 1200 V
CAL 14 1200 V
100V)
1.000kV)
Calibration Calibration
Range Point
3mA Offset 0.12mA
3mA Full 2.5mA
40mA Offset 2.5mA
40mA Full 25mA
3mA Offset 0.12mA
3mA Full 2.5mA
12mA Offset 2.5mA
12mA Full 10mA
150799 Rev A3
Resistance
(Load)
10MΩ
420kΩ
420kΩ
50kΩ
10MΩ
420kΩ
420kΩ
150kΩ
