QuadTech Guardian 6100 Plus Instruction Manual page 104

2.6.9 Part No.
The PART NUMBER function allows the operator to assign a part number to the device
under test.
keypad so the backlit box is to the right of Part No. Use the numerical keys to select first
character then use [NEXT CHAR] to move the underscore cursor to the next character.
When finished entering the part number string, press [ENTER]. The part number can be
made up of 0-13 alpha or numeric characters.
PRESET SETUP
01. Pass Hold
02. Step Hold
03. AC Freq.
04. GB Freq.
05. IEC - 601
06. GB Voltage
07. Auto Range
08. Soft AGC
09. Part No.
10. Lot No.
11. Serial No.
12. Start Wait
Example Part No.: EX2000
2.6.10 Lot No.
The LOT NUMBER function allows the operator to assign a lot number to the device
under test.
keypad so the backlit box is to the right of Lot No. Use the numerical keys to select first
character then use [NEXT CHAR] to move the underscore cursor to the next character.
When finished entering the lot number string, press [ENTER]. The lot number can be
made up of 0-13 alpha or numeric characters.
PRESET SETUP
01. Pass Hold
02. Step Hold
03. AC Freq.
04. GB Freq.
05. IEC - 601
06. GB Voltage
07. Auto Range
08. Soft AGC
09. Part No.
10. Lot No.
11. Serial No.
12. Start Wait
Example Lot No.: 092005
Page 104 of 177
www.valuetronics.com
To access Part No., press [PRESET] and then the [↓] or [↑] arrow on the
: 0.5 sec
: 0.3 sec
: 64 Hz
NEXT CHAR.
: 60 Hz
: OFF
: 15.0 V
: OFF
: ON
:
:
:
: OFF
Remote Lock Offset Error
To access Lot No., press [PRESET] and then the [↓] or [↑] arrow on the
: 0.5 sec
: 0.3 sec
: 64 Hz
NEXT CHAR.
: 60 Hz
: OFF
: 15.0 V
: OFF
: ON
EX2000
:
:
:
: OFF
Remote Lock Offset Error
Use Function Key [NEXT CHAR] to move cursor to next character
Use Numeric Keys then [ENTER]
Enter the Message: 0 - 13 alpha-numeric characters
PRESS
[2] 3x E [ENTER]
[8] 3x X [ENTER]
[2] 1x 2 [ENTER]
[0] 1x 0 [ENTER]
[0] 1x 0 [ENTER]
[0] 1x 0 [ENTER]
[ENTER]
[EXIT]
Use Function Key [NEXT CHAR] to move cursor to next character
Use Numeric Keys then [ENTER]
Enter the Message: 0 - 13 alpha-numeric characters
PRESS
[0] 1x 0 [ENTER]
[9] 1x 9 [ENTER]
[2] 1x 2 [ENTER]
[0] 1x 0 [ENTER]
[0] 1x 0 [ENTER]
[5] 1x 5 [ENTER]
[ENTER]
[EXIT]
150799 Rev A3
[NEXT CHAR]
[NEXT CHAR]
[NEXT CHAR]
[NEXT CHAR]
[NEXT CHAR]
[NEXT CHAR]
[NEXT CHAR]
[NEXT CHAR]
[NEXT CHAR]
[NEXT CHAR]
[NEXT CHAR]
[NEXT CHAR]
Operation
