OSC Programming – continued from last page.
Scanner #1 is the internal 6000-07 Hipot/Leakage Current Scanner. In OSC mode, only
Channels 1 and 3 are available on Scanner #1. CH1 can be set to H or X. CH3 can be set
to H, L or X.
STEP SETTING
01. Test Step
02. Test Mode
03. Open Chk.
04. Short Chk.
05. CHAN (H-L)
1
X
PRESS NUMBER KEYS
Press [1] to set Channel 1 to H (High)
Press [3] twice to set Channel 3 to L (Low)
This will check the connection between channels 1 and 3.
Press the function key [EXIT] to return to OSC program menu.
Press DOWN arrow [⇓]
The backlit box is now again at the top of the list adjacent to "Test Step: ___2___ ". STOP.
To continue programming the 7-step example:
Press the function key [UP] to select Test Step = 3. Instructions continued in ¶
OR
To End Programming and perform an OSC test:
Press [MENU] to exit program mode.
Perform offset (¶2.7.1), perform Get Cs (¶2.7.2), connect DUT (¶2.7.3) then press green
[START] button.
2.4.3 Programming an AC Hipot Test
In an AC hipot test, high AC voltage is applied between the DUT's operating circuits and
chassis ground to determine if/when a breakdown will occur in the insulation of the DUT.
The current is measured between the DUT insulation and ground. A high limit is
required in an AC test. The high limit is the maximum allowed value for the test to be
considered a PASS. If the measured value is higher than the high limit the test is
considered a FAIL.
If not already in PROGRAM mode:
Press [MENU] to access the PROGRAM menu
Press the function key [PROGRAM]
Page 60 of 177
www.valuetronics.com
: 2
: OSC
50%
:
300%
:
SETUP SCANNER - 1
: OFF
2 3 4 5 6 7 8
X X X X X X X
Remote Lock
NEXT BOX
EXIT
Offset Error
150799 Rev A3
Use Numeric Keys then [ENTER]
Use the Numeric Key that corresponds to the Channel #
The Numeric Key acts as a toggle switch: X, H or L
Program the scanner channels
X = Not used
H = High (High voltage/current applied to this channel)
L = Low (This channel is the return)
Press Function Key [NEXT BOX] to setup next scanner
Press Function Key [EXIT] to exit scanner setup
