QuadTech Guardian 6100 Plus Instruction Manual page 34

2.3
When powered ON, the G6100 instrument will boot to the MAIN MENU display. At
any time, press [MENU] to return to the MAIN MENU display. Within the MAIN
MENU there are 7 vertical sub-menus: System, Option, Calibration, Key Lock, New
Security Code, Fail Lock and Error Log. To access any of these 7 vertical sub-menus,
press the numerical key that corressponds to the menu. There are 4 functional menus on
the right side of the MAIN MENU display: Memory, Preset, Program and Test. To
access any of these 4 sidebar menus, press the function key to the right of the display that
corresponds to the sidebar menu. Refer to Figure 2-1.
1
SYSTEM
Contrast
Beeper Volume
Compensate
DC 50V AGC
Discharge - V
Pass ON
Use Source
After Fail
AC Offset
LC Offset
IEEE-488.1
3
CALIBRATION
(Need password to enter)
5
NEW SECURITY CODE
(Need password to enter)
7
ERROR LOG
Page 34 of 177
www.valuetronics.com
MAIN MENU
"STAND BY" or "Power-Up" Display
MAIN MENU
1 SYSTEM
2 OPTION
3 CALIBRATION
4 KEY LOCK
5 NEW SECURITY CODE
6 FAIL LOCK
7 ERROR LOG
2
OPTION
RS-232
GPIB
SCANNER
PRINT
GB-C RATE
4
KEY LOCK
(Need password to enter)
6
FAIL LOCK
(Need password to enter)
MEMORY
PRESET
PROGRAM
TEST
Remote Lock Offset
MEMORY PRESET
Store Pass Hold
Recall Step Hold
Delete AC Frequency
GB Frequency
IEC - 601
GB Voltage
Auto Range
Software AGC
Part No.
Lot No.
Serial No.
Start W ait
Figure 2-1: MAIN MENU
