Press the function key [AC] to select mode = AC Hipot
Press DOWN arrow [⇓]
Press [1][.][5][0][0][ENTER] to set voltage = 1.500kV (1500V)
Press DOWN arrow [⇓]
Press [0][.][5][0][0][ENTER] to set the high current limit = 0.500mA
Press DOWN arrow [⇓]
Press [0][ENTER] to set low current limit = OFF
Press DOWN arrow [⇓]
Press [0][ENTER] to set arc current limit = OFF
Press DOWN arrow [⇓]
Press the function key [3 -230 kHz] to set arc filter frequency = 3 – 230kHz
Press DOWN arrow [⇓]
Press [3][.][0][ENTER] to set test time = 3.0s
Press DOWN arrow [⇓]
Press [0][ENTER] to set ramp time = OFF
Press DOWN arrow [⇓]
Display reads: "10. CHNL (H-L) : OFF"
Press DOWN arrow [⇓] The backlit box is now again at the top of the list adjacent to
"Test Step: ___3___ ".
Press the function key [UP] to select Step # = 4
Press DOWN arrow [⇓]
Press the function key [PAGE1/2] then [PA] to select mode = Pause
Press DOWN arrow [⇓]
Enter Pause Message: "CHANGE LEAD"
Press DOWN arrow [⇓]
Press the function key [OFF] to set Under Test relay = OFF
Press DOWN arrow [⇓] The backlit box is now again at the top of the list adjacent to
"Test Step: ___4___ ".
Press the function key [UP] to select Step # = 5
Press DOWN arrow [⇓]
Press the function key [DC] to select mode = DC Hipot
Press DOWN arrow [⇓]
Press [2][.][4][0][0][ENTER] to set voltage = 2.400kV
Press DOWN arrow [⇓]
Press [0][.][5][0][0][ENTER] to set high current limit = 0.500mA
Press DOWN arrow [⇓]
Press [0][ENTER] to set low current limit = OFF
Press DOWN arrow [⇓]
Press [3][.][0][ENTER] to set dwell time = 3.0s
Press DOWN arrow [⇓]
Press [0][ENTER] to set arc current limit = OFF
Press DOWN arrow [⇓]
