Remote operation and automation of the Guardian 6100 Plus instrument can be
3.1
A 9 pin D-series remote control connector is located on the rear panel of the G6100 Plus
instrument. There is a black 6 screw relay strip for the remote output signals : UNDER
TEST, PASS & FAIL. There is a black 5 screw relay strip for the remote input
connections : START, RESET, COM & INTER LOCK.
closure and outputs provide a contact closure, as shown in Figure 3-1.
Before connecting the instrument to its power source the interlock function on the rear
panel remote connector must be properly utilized. This is an important safety feature
for the protection of the operator.
prohibited with no interlock connection and is functional with the interlock jumper in
place (as shipped from the factory).
The G6100 Plus unit has three output signals on the rear panel.
output terminal is short during TEST as the relay contacts connect to the device powered
by 115VAC and current < 0.3A.
judged GOOD. The FAIL output terminal is short when DUT is judged NO-GOOD.
Interface
www.valuetronics.com
Section 3 : Interface
accomplished using QuadTech's CaptivATE
Remote
UNDER
TEST
PASS
FAIL
11-Screw Terminal Strip
Figure 3-1: Remote Control Connections
