2.4.6 Programming an Insulation Resistance (IR) Test
In an IR test, high DC voltage is applied to the DUT to determine strength of the
insulation of the DUT. The resistance is measured between the DUT insulation and
ground. A low limit is required in an IR test. The low limit is the minimum allowable
value for the test to be considered a PASS. If the measured value is lower than the low
limit the test is considered a FAIL.
If not already in PROGRAM mode:
Press [MENU] to access the PROGRAM menu
Press the function key [PROGRAM]
If continuing example:
* Press the function key [UP] to select Step # = 6
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
SELECT STEP
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
SELECT MODE
Press the function key [IR] to select mode = Insulation Resistance
Continued on next page.
Page 72 of 177
www.valuetronics.com
1
:
: GB
: OFF
100.0m Ω
:
DOWN
: OFF
: 3.0s
: OFF
OFF
:
INSERT
DELETE
Remote Lock Offset
GB
: 6
GB
:
OFF AC
:
100.0m Ω
:
DC
: OFF
: 3.0s
IR
: OFF
OFF
:
LC
PAGE 1/2
Remote Lock Offset
Use Function Key
Toggle UP: 1 - 50
UP
Toggle DOWN: 50 - 1
Add a step
Remove a step
Error
Use Function Key
Ground Bond
AC Hipot
DC Hipot
Insulation Resistance
Leakage Current
Go to Page 2 (PA, OSC)
Error
150799 Rev A3 Operation
