QuadTech Guardian 6100 Plus Instruction Manual page 105

2.6.11 Serial No.
The SERIAL NUMBER function allows the operator to assign a serial number to the
device under test. To access Serial No., press [PRESET] and then the [↓] or [↑] arrow on
the keypad so the backlit box is to the right of Serial No. Use the numerical keys to
select first character then use [NEXT CHAR] to move the underscore cursor to the next
character. When finished entering the serial number string, press [ENTER]. The serial
number can be made up of 0-13 alpha or numeric characters.
PRESET SETUP
01. Pass Hold
02. Step Hold
03. AC Freq.
04. GB Freq.
05. IEC - 601
06. GB Voltage
07. Auto Range
08. Soft AGC
09. Part No.
10. Lot No.
11. Serial No.
12. Start Wait
Example Serial No.: AN456000
Operation
www.valuetronics.com
: 0.5 sec
: 0.3 sec
: 64 Hz
NEXT CHAR.
: 60 Hz
: OFF
: 15.0 V
: OFF
: ON
EX2000
:
092005
:
:
: OFF
Remote Lock Offset Error
150799 Rev A3
Use Function Key [NEXT CHAR] to move cursor to next character
Use Numeric Keys then [ENTER]
Enter the Message: 0 - 13 alpha-numeric characters
PRESS
[1] 2x A [ENTER] [NEXT CHAR]
[5] 3x N [ENTER] [NEXT CHAR]
[4] 1x 4 [ENTER] [NEXT CHAR]
[5] 1x 5 [ENTER] [NEXT CHAR]
[6] 1x 6 [ENTER] [NEXT CHAR]
[0] 1x 0 [ENTER] [NEXT CHAR]
[0] 1x 0 [ENTER] [NEXT CHAR]
[0] 1x 0 [ENTER] [NEXT CHAR]
[ENTER]
[EXIT]
Page 105 of 177
