GB Programming – continued from last page.
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
0, 0.3 - 999s
Press [3][.][0] to set the test time = 3.0 seconds
To illustrate the 7 separate modes in this example, Twin Port will be turned OFF. OSC
cannot be used when Twin Port is ON. For Twin Port details refer to ¶2.4.1.1.
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
PRESS FUNCTION KEY
Press the function key [OFF] to perform GB and AC separately (for this example)
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
PRESS FUNCTION KEY
Continued on next page.
Operation
www.valuetronics.com
: 1
: GB
: 30.0A
: 100.0mΩ
: OFF
3.0s
:
: OFF
OFF
:
0=CONT
Remote Lock Offset
: 1
GB
:
: 30.0A
: 100.0mΩ
: OFF
: 3.0s
OFF
:
OFF
:
Remote Lock Offset
: 1
: GB
30.0A
:
: 100.0mΩ
: OFF
: 3.0s
: OFF
OFF
:
Remote Lock Offset
150799 Rev A3
Use Numeric Keys then [ENTER]
Enter the Test Time in seconds (s)
0, 0.3 - 999s
Error
Note:
Use Function Key
Select Twin Port ON or OFF
ON: GB & Hipot/IR Tests performed simultaneously
ON
OFF: Tests performed singularly
OFF
Error
Use Function Key
SETUP
Enter setup menu for scanner(s)
Error
0 = Continuous
