2.4.8 Programming a Multi-Step Test
A total of 100 tests can be programmed and each test can consist of 1 to 50 steps in
sequence. Each step may be programmed for any available function (GB, AC, DC, IR,
LC, PA or OSC) with programmed test conditions independent from the other step.
Contained in this paragraph are the text instructions to program the example 7-step test as
shown in Table 2-5 in ¶ 2.4. For this example, the scanner channels have been set to
OFF except for LC mode. Instructions to save this example are given at the conclusion of
this section. Store and Recall instructions are detailed in paragraph 2.5.
Press the function key [UP] or [DOWN] to select Step # = 1
Press DOWN arrow [⇓]
Press the function key [GB] to select mode = Ground Bond
Press DOWN arrow [⇓]
Press [3][0][ENTER] to set current = 30A
Press DOWN arrow [⇓]
Press [1][0][0][ENTER] to set high limit = 100mΩ
Press DOWN arrow [⇓]
Press [0][ENTER] to set low limt = OFF
Press DOWN arrow [⇓]
Press [3][.][0] to set the test time = 3.0 seconds
Press DOWN arrow [⇓]
Press the function key [OFF] to perform GB and AC seperately
Press DOWN arrow [⇓]
Display reads: "8. CHNL (H-L) : OFF"
Press DOWN arrow [⇓]
The backlit box is now again at the top of the list adjacent to "Test Step: ___1___ ".
Press the function key [UP] to select Step # = 2
Press DOWN arrow [⇓]
Press the function key [PAGE1/2] then [OSC] to select mode = Open/Short Circuit
Press DOWN arrow [⇓]
Press [5][0][ENTER] to set the Open Check = 50%
Press DOWN arrow [⇓]
Press [3][0][0][ENTER] to set the Short Check = 300%
Press DOWN arrow [⇓]
Display reads: "5. CHNL (H-L) : OFF"
Press DOWN arrow [⇓]
The backlit box is now again at the top of the list adjacent to "Test Step: ___2___ ".
Press the function key [UP] to select Step # = 3
Press DOWN arrow [⇓]
Operation
150799 Rev A3
Page 93 of 177
