2.6.3 AC Frequency
To access AC Frequency, press [PRESET] and then the [↓] or [↑] arrow on the keypad so
the backlit box is to the right of AC Frequency. Use the numerical keys then [ENTER] to
enter the frequency in hertz. The range is 50-600Hz and the default setting is 60Hz.
2.6.4 GB Frequency
To access GB Frequency, press [PRESET] and then the [↓] or [↑] arrow on the keypad so
the backlit box is to the right of GB Frequency. Use the function key [50Hz] or [60Hz]
to select the frequency for the ground bond test in hertz. The range is 50/60Hz and the
default setting is 60Hz.
Operation
www.valuetronics.com
PRESET SETUP
01.
Pass Hold
:
02.
Step Hold
:
03.
AC Freq.
:
04.
GB Freq.
:
05.
IEC - 601
:
06.
GB Voltage
:
07.
Auto Range
:
08.
Soft AGC
:
09.
Part No.
:
10.
Lot No.
:
11.
Serial No.
:
12.
Start W ait
:
KEY, 0.1 - 99.9s
Dwell
STEP 1
Ramp
Test Time
Figure 2-19: Hold Times
