2.6.7 Auto Range
In an AC or DC Hipot test, the Auto Range setting permits the use the full scale current
range (ON) or using the user programmed maximum current limit (OFF).
current range (3mA full scale for AC; 300µA for DC) results in increased measurement
resolution.
measurement is close to the range limitation.
To access Auto Range, press [PRESET] and then the [↓] or [↑] arrow on the keypad so
the backlit box is to the right of Auto Range. Use the function key [ON] or [OFF] to turn
the source ON or OFF. The default setting is OFF.
2.6.8 Software AGC
The Software Automatic Gain Control (AGC) setting allows the option of correcting the
output voltage (ON). This is may be beneficial when measuring resistors but under
special circumstances when measuring large capacitive devices it is best to select Soft.
AGC OFF.
Refer to paragraph 2.3.1.4 for additional AGC information.
To access Software AGC, press [PRESET] and then the [↓] or [↑] arrow on the keypad
so the backlit box is to the right of Software AGC. Use the function keys [ON] or [OFF]
to turn the software automatic gain control ON or OFF. The default setting is ON.
Operation
www.valuetronics.com
PRESET SETUP
01. Pass Hold :
02. Step Hold :
03. AC Freq. :
04. GB Freq. :
05. IEC - 601 :
06. GB Voltage :
07. Auto Range :
08. Soft AGC :
09. Part No. :
10. Lot No. :
11. Serial No. :
12. Start W ait :
6.0 - 15.0V
Note: setting Auto Range to ON may induce erratic results if the
PRESET SETUP
01. Pass Hold :
02. Step Hold :
03. AC Freq. :
04. GB Freq. :
05. IEC - 601 :
06. GB Voltage :
07. Auto Range :
08. Soft AGC :
09. Part No. :
10. Lot No. :
11. Serial No. :
12. Start Wait :
PRESS FUNCTION KEY
PRESET SETUP
01. Pass Hold :
02. Step Hold :
03. AC Freq. :
04. GB Freq. :
05. IEC - 601 :
06. GB Voltage :
07. Auto Range :
08. Soft AGC :
09. Part No. :
10. Lot No. :
11. Serial No. :
12. Start Wait :
PRESS FUNCTION KEY
150799 Rev A3
0.5 sec
0.3 sec
64 Hz
60 Hz
OFF
15.0 V
OFF
ON
OFF
Remote Lock Offset Error
0.5 sec
0.3 sec
64 Hz
ON
60 Hz
OFF
15.0 V
OFF
OFF
ON
OFF
Remote Lock Offset Error
0.5 sec
0.3 sec
64 Hz
ON
60 Hz
OFF
15.0 V
OFF
OFF
ON
OFF
Remote Lock Offset Error
The low
