QuadTech Guardian 6100 Plus Instruction Manual page 40

2.3.1.8
The After Fail function lets the programmer instruct the G6100 Plus how to proceed
when a test result is a FAIL. To access After Fail, enter System Setup by pressing
[MENU], [1] and the [↓] or [↑] arrow on the keypad so the backlit box is to the right of
After Fail. Use the function keys [CONTINUE], [STOP] or [START] to instruct the
instrument to continue on fail, stop on fail or re-start on fail.
When "Continue on Fail" is selected, the Guardian 6100 Plus will continue to run any
remaining steps that are programmed after the step in which the Fail occurred. The
Guardian 6100 Plus will then indicate a failure at the end of the test.
Selecting "Start on Fail" is useful for automated systems. Typically when a failure
occurs, the instrument requires a STOP signal to be sent (or the [STOP] button pressed).
Selecting "Start on Fail" deactivates the requirement to send a stop signal.
The default setting is "Stop on Fail". When a failure occurs, the Guardian 6100 Plus
instrument will stop at the time of failure. A STOP signal is required to begin testing
again.
Page 40 of 177
www.valuetronics.com
After Fail
SYSTEM SETUP
01. Contrast :
02. Beeper Vol. :
03. Compensate :
04. DC 50V AGC :
05. Discharge - V :
06. Pass ON :
07. Use Source :
08. After Fail :
09. AC Offset :
10. LC Offset :
11. IEEE-488.1 :
STOP/START/CONT.
17
HIGH
CONTINUE
20%
ON
3.10kV START
1.0s
STOP
OFF
STOP
0.5mA
0.00mA
ON
Remote Lock Offset Error
150799 Rev A3 Operation
