2.4.1 Programming a Ground Bond (GB) Test
In a GB test, high AC current is applied between a conductive surface of the DUT and
ground connection. The ground circuit resistance is then calculated and displayed. A
high limit is required in a GB test. The high limit is the upper value for the test to be
considered a PASS. If the measured value is higher than the high limit the test is
considered a FAIL.
The Function Keys allow you to select the backlit item. Use the [↑] and [↓] arrow keys
Press [MENU] to access the PROGRAM menu
Press the function key [PROGRAM]
Press the function key [UP] or [DOWN] to select Step # = 1
STEP SETTING
01.
Test Step
02.
Test Mode
03.
Current
04.
High Limit
05.
Low Limit
06.
Test Time
07.
Twin Port
08.
CHNL (H-L)
SELECT STEP
Press DOWN arrow [⇓]
STEP SETTING
01.
Test Step
02.
Test Mode
03.
Current
04.
High Limit
05.
Low Limit
06.
Test Time
07.
Twin Port
08.
CHNL (H-L)
SELECT MODE
Press the function key [GB] to select mode = Ground Bond
Continued on next page.
Operation
www.valuetronics.com
Note – Moving through Menus
or the [ENTER] key to move up and down the list.
:
1
:
GB
:
OFF
:
100.0mΩ
DOWN
:
OFF
:
3.0s
:
OFF
OFF
:
INSERT
DELETE
Remote
Lock
Offset
:
1
GB
:
:
OFF
:
100.0mΩ
:
OFF
:
3.0s
:
OFF
OFF
:
PAGE 1/2
Remote
Lock
Offset
150799 Rev A3
Use Function Key
UP
Toggle UP: 1 - 50
Toggle DOWN: 50 - 1
Add a step
Remove a step
Error
Use Function Key
GB
Ground Bond
AC
AC Hipot
DC
DC Hipot
Insulation Resistance
IR
LC
Leakage Current
Go to Page 2 (PA, OSC)
Error
Page 53 of 177
