QuadTech Guardian 6100 Plus Instruction Manual page 119

2.7.3.8
The G45 40A Ground Bond Transformer comes with two lead sets, one to connect
G6100 Drive/Sense terminals to the G45 INPUT terminals and the second to connect the
G45 OUTPUT terminals to the DUT. Make the connection to the INPUT Drive +/Drive-
terminals with the spade lug positioned behind the nut.
Connect the Spade-to-Spade lead set between the G6100 Drive/Sense terminals and the
G45 INPUT terminals. The red wire between Drive +/Drive+. The black wire between
Drive-/Drive-.
Banana/Spade-to-Alligator lead set between the G45 OUTPUT terminals and the DUT.
STOP
START
ON
1
0
OFF
Front G45
Operation
www.valuetronics.com
G45 40A Ground Bond Transformer
The blue spades to Sense+ and Sense- terminals.
QuadTech
Guardian 6100 Plus
Electrical Safety Analyzer
GROUND BOND 40A
Figure 2-32: G45 connection to G6100 Plus
MENU
1
4
7
0
CAL UPDATE
Rear G45
OUTPUT
SENSE - SENSE + SENSE -
DRIVE - DRIVE + DRIVE -
(-) (+)
DUT
Low High
Screw SPADE behind bolt
150799 Rev A3
Connect the
TM
Twin
PRINT LOCAL
Por t s
DANGER
2 3
HIGH
VOLTAGE
CAUTION!
!
Max: 5kVAC
5 6
6kVDC
OUTPUT
PASS FAIL
8 9
. CLR
Drive Sense Sense Drive
-
+
ENTER
INPUT
SENSE +
DRIVE +
NOTE:
INPUT Terminals
DRIVE- DRIVE+
Page 119 of 177
SPADE lug
