QuadTech Guardian 6100 Plus Instruction Manual page 75

IR Programming – continued from last page.
Scanner #1 is the internal 6000-07 Hipot/Leakage Current Scanner. In IR mode, only
Channels 1 and 3 are available on Scanner #1. CH1 can be set to H or X. CH3 can be set
to H, L or X.
STEP SETTING
01. Test Step
02. Test Mode
03. Voltage
04. Low Limit
05. High Limit
1
06. Test Time
X
07. Ramp Time
08. CHAN (H-L)
PRESS NUMBER KEYS
Press [1] to set Channel 1 to H (High)
Press [3] twice to set Channel 3 to L (Low)
Press the function key [EXIT] to return to IR program menu.
Press DOWN arrow [⇓]
The backlit box is now again at the top of the list adjacent to "Test Step: ___6___ ". STOP.
To continue programming the 7-step example:
Press the function key [UP] to select Test Step = 7. Instructions continued in ¶
OR
To End Programming and perform an IR test:
Press [MENU] to exit program mode.
Perform offset (¶2.7.1), perform Get Cs (¶2.7.2), connect DUT (¶ 2.7.3) then press green
[START] button.
Operation
www.valuetronics.com
: 6
: IR
: 1.000kV
0.100M Ω
SETUP SCANNER - 1 :
: OFF
2 3 4 5 6 7 8
: 3.0s
X X X X X X X
: OFF
: OFF
Remote Lock
NEXT BOX
EXIT
Offset Error
150799 Rev A3
Use Numeric Keys then [ENTER]
Use the Numeric Key that corresponds to the Channel #
The Numeric Key acts as a toggle switch: X, H or L
Program the scanner channels
X = Not used
H = High (High voltage/current applied to this channel)
L = Low (This channel is the return)
Use Function Key [NEXT BOX] to setup next scanner
Use Function Key [EXIT] to exit scanner setup
