QuadTech Guardian 6100 Plus Instruction Manual page 41

2.3.1.9
The AC Offset function determines how the AC offset value will be applied to the
displayed current reading. If the measured offset value is higher than the programmed
AC Offset value then the Displayed Current = (Measured value) – (Offset value). If the
measured offset is lower than the AC offset value then the Displayed Current = the
square root of (Measured value)
To access AC Offset, enter System Setup by pressing [MENU], [1] and the [↓] or [↑]
arrow on the keypad so the backlit box is to the right of AC Offset. Use the numerical
keys then [ENTER] to enter the current in mA. The range for AC Offset is 0 – 2.5mA and
the default value is 0.5mA.
2.3.1.10
This function is valid for the Guardian 6100 Plus line leakage test only. If the measured
offset value is higher than the programmed LC Offset value then the Displayed Current =
(Measured value) – (Offset value). If the measured offset is lower than the LC offset
value then the Displayed Current = the square root of (Measured value)
2
value)
To access LC Offset, enter System Setup by pressing [MENU], [1] and the [↓] or [↑]
arrow on the keypad so the backlit box is to the right of LC Offset. Use the numerical
keys then [ENTER] to enter the current in mA. The range for LC Offset is 0 – 2.5mA and
the default value is 0.0mA.
Operation
www.valuetronics.com
AC Offset
SYSTEM SETUP
01. Contrast
02. Beeper Vol.
03. Compensate
04. DC 50V AGC
05. Discharge - V
06. Pass ON
07. Use Source
08. After Fail
09. AC Offset
10. LC Offset
11. IEEE-488.1
0 - 2.5mA
LC Offset
.
SYSTEM SETUP
01. Contrast
02. Beeper Vol.
03. Compensate
04. DC 50V AGC
05. Discharge - V
06. Pass ON
07. Use Source
08. After Fail
09. AC Offset
10. LC Offset
11. IEEE-488.1
0 - 2.5mA
2 2
– (Offset value) .
: 17
: HIGH
: 20%
: ON
: 3.10kV
: 1.0s
: OFF
: STOP
: 0.5mA
: 0.00mA
: ON
Remote Lock Offset
: 17
: HIGH
: 20%
: ON
: 3.10kV
: 1.0s
: OFF
: STOP
: 0.5mA
: 0.00mA
: ON
Remote Lock Offset
150799 Rev A3
Error
2
Error
Page 41 of 177
– (Offset
