2.4.4 Pause (PA) Mode
"PAUSE" is a mode selection that allows a test sequence to be stopped while test leads
are changed or other operations performed. A 13-character user programmable message
will be displayed on the screen when in PAUSE mode and the test will continue when the
[START] button is pressed or START initiated via remote I/O. The Under Test relay on
the remote I/O can also be cycled during PAUSE if required.
If not already in PROGRAM mode:
Press [MENU] to access the PROGRAM menu
Press the function key [PROGRAM]
If continuing example:
* Press the function key [UP] to select Step # = 4
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
SELECT STEP
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
SELECT MODE
STEP SETTING
01. Test Step
02. Test Mode
03. Current
04. High Limit
05. Low Limit
06. Test Time
07. Twin Port
08. CHNL (H-L)
SELECT MODE
Press the function key [PAGE1/2] then [PA] to select mode = Pause
Operation
www.valuetronics.com
1
:
: GB
: OFF
100.0m Ω
:
DOWN
: OFF
: 3.0s
: OFF
OFF
:
INSERT
DELETE
Remote Lock Offset
: 4
GB
:
: OFF
100.0m Ω
:
: OFF
: 3.0s
: OFF
OFF
:
PAGE 1/2
Remote Lock Offset
: 4
GB
:
: OFF
100.0m Ω
:
: OFF
: 3.0s
: OFF
OFF
:
PAGE 2/2
Remote Lock Offset
150799 Rev A3
Use Function Key
UP Toggle UP: 1 - 50
Toggle DOWN: 50 - 1
Add a step
Remove a step
Error
Use Function Key
Ground Bond
GB
AC AC Hipot
DC
DC Hipot
IR Insulation Resistance
LC Leakage Current
Go to Page 2 (PA, OSC)
