2.7.4 Measurement Procedure
Before a measurement is made, verify the following:
Perform a test at power-up conditions (test conditions at which the instrument was last
powered down), or recall one of 100 possible stored setups. Refer to paragraphs 2.4 and
2.5 for instructions to change the test mode and/or test conditions.
To initiate a test at "power-up conditions" proceed as follows:
2.7.5 Viewing Test Results
Test results are displayed upon completion of a test in the right hand column labeled
'RES.". Use [PAGE UP] or [PAGE DOWN] to view additional steps over 10.
2.8
The [PRINT] button on the front panel of the G6100 Plus instrument is used when the
Printer interface is installed. Press [PRINT] to print out the Test results as shown on the
display.
2.9
The [LOCAL] button on the front panel of the G6100 Plus instrument acts as a toggle
switch and is used when the G6100 Plus is being controlled via the RS-232 or IEEE-488
interface. The G6100 Plus is in remote status when the REMOTE LED is ON. To switch
to Local from Remote press the [LOCAL] function key. The [LOCAL] and [STOP]
buttons are the only functional keys when the unit is in REMOTE mode.
Page 120 of 177
www.valuetronics.com
• Guardian 6100 Plus unit power is ON
• 15 minute warm-up
• Test parameters programmed
• Offset function completed
• OSC – Get Cs completed
• Device Under Test (DUT) connected
1 Press [TEST] to enter Test Menu
2 Press [STOP] Offset LED is backlit
3 Press [START] Danger LED flashes, Offset LED is backlit
4 Press [STOP] At any time to stop test
PRINT
LOCAL
150799 Rev A3 Operation
