QuadTech Guardian 6100 Plus Instruction Manual page 62

AC Hipot Programming – continued from last page.
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Voltage
04. High Limit
05. Low Limit
06. Arc Limit
07. Arc Filter
08. Test Time
09. Ramp Time
10. CHNL (H-L)
0.05 - 5 kV
Press [1][.][5][0][0][ENTER] to set voltage = 1.500kV
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Voltage
04. High Limit
05. Low Limit
06. Arc Limit
07. Arc Filter
08. Test Time
09. Ramp Time
10. CHNL (H-L)
0.001 - 40 mA
Press [0][.][5][0][0][ENTER] to set high current limit = 0.500mA
Press DOWN arrow [⇓]
STEP SETTING
01. Test Step
02. Test Mode
03. Voltage
04. High Limit
05. Low Limit
06. Arc Limit
07. Arc Filter
08. Test Time
09. Ramp Time
10. CHNL (H-L)
0 - 40 mA
Press [0][ENTER] to set low current limit = OFF
Continued on next page.
Page 62 of 177
www.valuetronics.com
3
:
:
AC
OFF
:
: 0.500mA
OFF
:
OFF
:
3-230 kHz
:
3.0s
:
OFF
:
OFF
:
Remote Lock Offset
: 3
: AC
1.500kV
:
0.500mA
:
: OFF
OFF
:
3-230 kHz
:
3.0s
:
OFF
:
OFF
:
Remote Lock Offset
3
:
: AC
1.500kV
:
: 0.500mA
OFF
:
OFF
:
3-230 kHz
:
3.0s
:
OFF
:
OFF
:
0 = OFF
Remote Lock Offset
Use Numeric Keys then [ENTER]
Enter the Test Voltage in kilo-volts (kV)
0.05 - 5 kV (50 - 5000 V)
Error
Use Numeric Keys then [ENTER]
Enter the High Limit in milli-amps (mA)
0.001 - 40 mA
Error
Use Numeric Keys then [ENTER]
Enter the Low Limit in milli-amps (mA)
0 - 40 mA, 0 = OFF
Error
150799 Rev A3 Operation
