QuadTech Guardian 6100 Plus Instruction Manual page 114

STOP
START
ON
1
0
OFF
DUT
(Monitor)
Figure 2-27: Connection for Hipot Test (Using G14 Power Entry Cable)
Page 114 of 177
www.valuetronics.com
QuadTech
Guardian 6100 Plus
Electrical Safety Analyzer
Remove DUT's power cord
from AC inlet module
Plug G14 Adaptor into
DUT's AC inlet module
150799 Rev A3
MENU PRINT LOCAL
1 2 3
4 5 6
7 8 9
0 . CLR
ENTER
CAL UPDATE
G14 Power Entry Adaptor
NOTE:
Make the connection to the DRIVE+ and DRIVE-
terminals with the spade lug behind the nut. Use the
Bushing Driver Tool included to secure the nut as
shown here.
DRIVE+ and DRIVE-
Output Terminals
TM
Twin
Por t s
White
Custom
Banana
DANGER
HIGH
VOLTAGE Plug
CAUTION! to
!
Max: 5kVAC
OUTPUT
6kVDC
OUTPUT
PASS FAIL
Drive Sense Sense Drive
+ -
Black
Spade
Lug
to Drive-
Black Banana
Plug with
Retaining
Bracket
to Sense-
Screw SPADE between bolt
and second connector
SPADE lug
Operation
