Press the function key [VOLTAGE] to set power = Voltage mode
Press DOWN arrow [⇓]
Press [3][0][0][ENTER] to set high power limit = 300V
Press DOWN arrow [⇓]
Press [0][ENTER] to set low power limit = OFF
Press the function key [EXIT] to exit power setup
Press DOWN arrow [⇓]
Press [3][.][0][ENTER] to set test time = 3.0s
Press DOWN arrow [⇓]
Display reads: "11. CHNL (H-L) : OFF"
Press the function key [SETUP] to enter scanner setup menu
Press [3] once to set Channel 3 to L (Low)
Press the function key [EXIT] to return to LC program menu.
Press DOWN arrow [⇓] The backlit box is now again at the top of the list adjacent to
"Test Step: ___7___ ".
Press [MENU] to exit program mode.
Set Preset (¶2.6)
Perform Offset (¶2.7.1)
Perform Get Cs (¶2.7.2)
Press the function key [MEMORY] The backlit box is adjacent to location 1: "1. (0) :
______ ".
Press DOWN arrow [⇓] to move backlit box to selected location (3 for this example).
Press the function key [STORE]
Use numeric keypad to name memory location (up to 13 alpha-numeric characters).
Press [ENTER] then [NEXT CHAR.] to move cursor to next character.
Name this setup "EXAMPLE".
Press [ENTER] when finished: "3. (_7) : EXAMPLE ".
Message: "STORE? Press ENTER to continue"
Press [ENTER]
Press MENU
Press the function key [TEST]
End of example.
