QuadTech Guardian 6100 Plus Instruction Manual page 36

2.3.1.1
To access Contrast, press [MENU], [1] and the [↓] or [↑] arrow on the keypad so the
backlit box is to the right of Contrast. Use the function keys [UP] or [DOWN] to
increase or decrease the contrast. The display Contrast is adjustable from 1 – 31.
value of 1 is brightest , a value of 31 is darkest. The default setting for Contrast is 17.
2.3.1.2
To access Beeper Volume, enter System Setup by pressing [MENU], [1] and the [↓] or
[↑] arrow on the keypad so the backlit box is to the right of Beeper Volume. Use the
function keys [LOW], [MEDIUM], [HIGH] or [OFF] to increase or decrease the volume.
The Beeper Volume can be set to OFF or to sound in a High, Medium or Low tone. The
default setting for Beeper Volume is HIGH.
The beeper will sound each time a button is pushed. It will beep at the end of a test and
will sound continuously until the [STOP] button is pressed when a fialure occurs. If an
arc occurs, the beeper will beep (although not a continuous alarm).
Page 36 of 177
www.valuetronics.com
Contrast
